Thrust Air Bearing Design and installation guide

Thrust air bushings slide over the shaft just like air bushings. The only differences is that thrust air bushings have face collars clamped to the shaft on both sides in order to keep the thrust air bushings from moving linearly. OAV Mounting Blocks can be used to hold the thrust air bushings. If a customer-designed housing is used, make sure to follow the same guidelines as shown below for air bushings.

thrust air bearing design and installation diagram

If the shaft is rotated with a drive-belt, it is best to use two thrust bearings per shaft to counteract the torque. The drive belt should always be placed between the thrust air bushings. If this is not possible, then keep the belt as close to the first thrust air bushing as possible. Statistical equations can be used to determine the load requirement on each thrust bushing.


The diagrams below show two common examples where F1 is the tension from the drive-belt, F2 & F3 are the forces acting on the bushings, and d1 and d2 are the distances from the center of the belt and thrust air bushings.

thrust air bearing labeled design

Design & Installation Guides

Figure 1. The drive belt in between both thrust air bushings. This is recommended, as the tension on the belt will be distributed amongst both thrust air bushings as shown in the equations below.

​

F3 = F1* d1/(d1+d2)

​

F2 = F1* d2/(d1+d2)

​

Assuming: d1 = d2:


F2 = F3 = .5*F1

thrust air bearing diagram

Figure 2. The drive belt outside the two thrust air bushings. This configuration works best with a small distance d1 and long distance d2. The corresponding load equations are below.

​

F2=F1*(d1/d2+ 1)

​

F3 = F1* d1/d2

​

Consider the gap between the bushing and the face collar as negligible. The face collar will be placed up against the frictionless surface of the thrust bushing. Once the air supply is turned on, a small gap will be created. Therefore, the total length of the thrust bushing system can be determined by the following formula:


length of the left face collar + length of thrust air bushing + length of right face collar

Housing Installation

The three methods of housing installation are epoxy, O-rings, or a light-press fit. OAV mounting blocks allow for the epoxy
and O-ring methods of installation. In most cases it is recommended to design using O-rings, because O-rings have self-
aligning features that can be readjusted.

​

Designing With Epoxy:

If epoxy is used, make sure that the epoxy grooves on the bushings can be accessed with a syringe.

​

Designing With O-rings:

If O-rings are used, make sure to use the appropriate bore size and tolerance. OAV can also provide this information.
​
Designing W
ith The Light-Press Fit Method:

If a light-press fit method is used, make sure to use the recommended bore size and tolerances. OAV can also provide this
information.

​

Other Considerations:

Air bushings rely on the straightness of the shaft. Design so that the deflection/displacement of the shaft is minimal.
Installing bushings with O-rings:

1) First do a quick visual inspection to ensure that there are no sharp edges in the bore of the mounting block. The o-rings
provide a very tight fit and if they get damaged, they will not work properly.
2) Lubricate the O-rings and surfaces with alcohol.
3) Press-fit the bushing inside the mounting block.
4) Insert the shaft and apply the air pressure. 30 PSI is enough to test the bushing without any load being applied.
5) Use proper alignment. If two shafts are used side-by-side, it is best to use gages to assure that the shafts are at an equal
distance from both ends. Parallelism is crucial for optimal performance of the air bushings.
​
Installing Bushings With Epoxy:

1) Clean the surfaces with alcohol.
2) Slide the air bushing into the mounting block, and the shaft into the bushing.
3) Align the shaft(s) with the best parallelism possible. If two shafts are used side-by-side, it is best to use gages to ensure
that the shafts are at equal distance at both ends. Parallelism is crucial for the performance of the air bushings.
4) Turn the air supply on at 30 PSI and do not apply any load to the bushing.
5) Use a syringe to apply the epoxy through the syringe holes on the mounting block until the epoxy fills the epoxy grooves
on the bushing. Make sure that the air port on the bushing lines up with the air port on the mounting block.
6) Keep the air supply on at 30 PSI until the epoxy cures.
7) Epoxy installation should only be performed after shaft alignment is confirmed
​

Installing Bushings With The Light-Press Fit Method:

1) Clean the surfaces with alcohol.
2) Light-press fit the air bushing into the mounting block, and the shaft into the bushing.
3) Align the shaft(s) with the best parallelism possible. If two shafts are used side-by-side, it is best to use gages to ensure
that the shafts are at equal distance at both ends. Parallelism is crucial for the performance of the air bushings.
4) Make sure that the air port on the bushing lines up with the clearance hole on the mounting block.
5) Install the air fitting directly into the air bushings as shown above.
Shaft and Face Collar Installation
1) Clean shaft surface with alcohol and a lint free cloth. Check for any surface imperfections. Shaft surface finish should
be 16 RMS or better.
2) Insert shaft in bushing with operating air on.
3) Clean face collar working surfaces with alcohol and a lint free cloth. Check for any surface imperfections.
4) Install first face collar in position on the shaft and tighten firmly.
5) Install second face collar on the shaft, press against the graphite thrust face with the operating air on, and tighten firmly. Gap will be set automatically by running air.

​

Mounting Alignment:

Mounting blocks should be installed in their permanent position after shaft install or secured loosely during shaft
installation. This will allow alignment adjustment between the block, O-ring compression, and running air. Mounting
blocks should be secured firmly after shaft installation and alignment is confirmed.

​

Temperature Controlled Thrust Air Bearings:

The temperature control bearings have three ports – the center port for bearing operating air, and ports on either side the
inlet and “exhaust” of temperature control fluid. Operating air and temperature control fluid do not interact withing the
bearing. Any fluid can be used, but air is most common. Operating air inlet and circulating fluid inlet should be
independent feeds to control pressure, flow, and temperature as needed.

​

​

​

​

​

​

​

OAV Tempertaure Controlled Thrust Air Bushing Design and Installation Guide

Extreme Temperature Conditions

At temperatures below freezing, water will be drawn out of the air and can crystallize internally, impeding flow and
degrading performance of the bearing. This crystallization can occur in both operating air and temp control fluid when air is
used. Severity and likelihood of occurrence are dependent on severity of temperature, operating pressures, flows, ambient
humidity. This can be counter acted by using:

1) An in-line air heater
2) Compressed air dehumidifier
3) Pure compressed gas, such as helium or nitrogen (where practical), due to the homogenous state lacking water
contamination.

At high temperatures, maximum exposure temperature is dependent on application and precision needs, and control may be
aided with refrigeration of air and circulating fluid.
